Titanium Alloy Tube





Titanium alloy tubes are formed from titanium alloys, which can be categorized into three groups according on how they are organized. (1 titanium with aluminium and tin elements. 2 titanium with aluminium chromium molybdenum vanadium and other alloying elements. 3 titanium with aluminium and vanadium and other elements.) They have high mechanical properties, excellent stamping properties, and can be welded in various forms, and the strength of welded joints can reach 90% of the strength of the base metal, and good cutting properties. Titanium tubes have high corrosion resistance to chlorides, sulphides and ammonia



Introducing the characteristics of titanium alloy tubes Titanium alloy tubes are a kind of titanium alloy material products, which are formed by drawing titanium alloy rods into hollow thin-walled tubes. Titanium alloy tubes have many excellent characteristics, such as light weight, high strength, good corrosion resistance and so on. In addition, titanium alloy has excellent formability and weldability, which can meet the requirements of different application occasions.

Light weight: The density of titanium alloy is only 4.5g/cm3, which is only 60% of stainless steel, and its specific strength is much higher than that of stainless steel. 2. High strength: The strength of titanium alloy is higher than that of stainless steel. Its strength is close to that of steel, but its density is much lower than that of steel, so its specific strength is much higher than that of steel.

Good corrosion resistance: Titanium alloy has good corrosion resistance in many media, such as seawater, alkali, acid, organic solvents, etc.

Good formability and weldability: Titanium alloy has good formability and weldability, which can meet the requirements of different application occasions.

Low temperature resistance: Titanium alloy has good low temperature resistance and can be used at a temperature of -253℃ without embrittlement.

Non-magnetic: Titanium alloy is non-magnetic and can be used in magnetic environment.



Product name: Titanium alloy tube

Material: Gr2 Gr5 Gr9, Gr1/Gr2/Gr3/Gr5/Gr7/Gr9/Gr12

Processing services: bending, welding, degreasing, cutting, punching

Shapes: round. Square. Rectangular, etc.

Payment: T/T (30% deposit + 70% prepayment)

Melting point: 1725℃

Titanium alloy impurities: oxygen, nitrogen, carbon and hydrogen









Permissible deviation of the outer diameter of titanium tubes（mm)
Outer diameter	3～10	>10~30	>30~50	>50~80	>80~100	>100
Allowable Deviation	±0.15	±0.30	±0.50	±0.65	±0.75	±0.85



Length of tubing (mm)
Titanium seamless tubes	Outer diameter	≤15	Indeterminate lengths	500~400
		15		500~900
Titanium welded tubes	Wall thickness	0.5~1.25		500~1500
		1.25~2.0		500~6000
Titanium welded-rolled tubes	Wall thickness	2.0~2.5		500~4000
		0.5~0.8		500~8000
		>0.8~2.0		500~5000





KeHui Titanium is a leading manufacturer of high quality titanium alloys. We specialise in the production of various grades of titanium ingots, rods, plates, tubes, forgings and zirconium and zirconium alloy products for a wide range of applications in the aerospace, medical and defence industries.



Our team of highly skilled and experienced engineers, technicians and metallurgists are dedicated to ensuring that our products maintain the highest standards of quality and consistency. We have also established a robust quality control system to ensure that every product that leaves our factory meets our strict quality standards.



In short, our company is a reliable and trustworthy source of high quality titanium products. With our commitment to quality, sustainability and innovation, we are confident that we can meet the unique needs of our customers and provide them with the best products and services in the industry.

Sizes can be customised to suit customer requirements



















Q: How about the quality control?
A: In addition to performing SGS tests, we also have our own quality control system. We can assist with additional third-party inspection if necessary.

Q: Do you accept OEM, ODM?
A: Yes, we can add your logo on the products upon request.



Q:Can I acquire a sample to evaluate your product's quality?

A: Yes, you can.





Hot Tags: titanium alloy tube, China titanium alloy tube manufacturers, suppliers, factory, mandrel bending titanium tubing, 2 titanium tubing, Titanium Seamless Tube, titanium tubing cost, titanium welded pipe, titanium pipe
