Titanium Alloy Plate





Titanium alloy plate with low density, high tensile strength, between -253-600℃, its ratio is close to the higher temperature in metal materials, in the appropriate oxidation conditions, can form a thin and hard oxide film, with good corrosion resistance. It also has no magnetic properties and a low coefficient of linear expansion. This method made titanium and titanium alloys firstly an important structural material for astronautics, and then was extended to ships, chemicals and other fields, and developed rapidly. Especially in the chemical industry, titanium and titanium alloys are used more and more widely, such as petrochemicals, fibres, pulp, fertilizers, electrochemistry, desalination, heat exchangers, reaction towers, synthesizers, autoclaves, etc. Titanium metal plates are used for electrolysis, desalination of sewage, as electrolytic plates, electrolytic tanks, reaction towers, reactors, etc.



The main component of titanium alloy plate is titanium, to which other elements have been added. Titanium alloy plate not only have a very low density, very high strength and very high corrosion resistance, but they are also characterised by very good workmanship and are now frequently used in the aviation industry.



tititanium alloy plate production specifications

T 0.5-1.0mm x W1000mm x L 2000-3500mm

T 1.0-5.0mm x W1000-1500mm x L 2000-3500mm

T 5.0- 30mm x W1000-2500mm x L 3000-6000mm

T 30- 80mm x W1000mm x L 2000mm



titanium alloy plate technical requirements

1:The chemical composition of titanium and titanium alloy plates shall conform to the provisions of GB/T 3620.1, and the permissible deviation of the chemical composition shall conform to the provisions of GB/T 3620.2 when the demand side is retested.

2: The corners of the sheets shall be cut at right angles as far as possible. The allowable deviation of the length and width of the sheet should not be exceeded when cutting at an angle.



Surface quality



Cracks, peeling, oxide, indentations, macroscopic flaws such metallic and non-metallic inclusions, and signs of excessive alkali washing are not permitted on the plate's surface.



The titanium plate may be free of small flaws in the rolling direction as long as the thickness after removal does not fall below the minimum allowable thickness.

In addition, the plate should not be delaminated.



Product name：Titanium alloy plate

Material: GR1, GR2, GR3, GR5, GR7, GR12

Tolerance range: ±0.05 mm

Place of origin: Baoji, China

Standard: ASTM B265. ASTM F136. ASTM F67. AMS4928

Production process: Hot forging, hot rolling, cold rolling, annealing, pickling













Room temperature mechanical properties of titanium sheets

Grades	Plate thickness （mm)	Room temperature performance not less than
		Tensile strengthσьMPa	Yield strengthσ0.2MPa	Elongationδ₅%	Bending angle α not less than
Gr1	0.3～10.0	370-530	250	45-30	140-130
Gr2	0.3～110.0	440~620	320	25	100-80
Gr5	0.8～10.0	895	830	12-10	35-30



High temperature mechanical properties of titanium sheet

Grades	Test temperature°C	High temperature mechanical properties not less than
		Tensile strengthσьMPa	Durable strength σ₁₀₀hMPa
Gr5	400 500	600 450	550 200





Kehui Titanium Co., Ltd. is a company specialising in the development and production of titanium technology and related products, and is committed to the development of the titanium industry.

Established in 2011, the company is located in Baoji City, Shaanxi Province, China, covering an area of 15,000 square meters, with first-class titanium processing equipment and testing instruments, mainly producing various types of titanium and titanium alloy plates, sheets, pipes, wires and other products, with a wide range of applications in aerospace, military, medical, power, petrochemical and other fields.

The company has a perfect quality management system and has established long-term cooperation with a number of well-known enterprises, so that the quality of its products has been greatly improved and recognized by the majority of customers.

















Q:How well does your factory do in terms of quality control?

A: Quality is a top priority. The people at Kehui Titanium take quality control very seriously from start to finish.



Q: What is the difference between you and other companies?

A: We are a manufacturer and we are committed to offering you the lowest prices and guaranteed quality.

We have our own processing facilities and can process any size to our customers' requirements.

We have 60,000 tonnes of conventional sizes in stock for delivery within 7 days. For customer orders, the production time is 15-30 working days after receipt of deposit.

Our own packaging team can ensure the best export standard packaging of goods without any damage.

We have our own material book and can also provide third party test certificates.



Q: Can I have my logo printed on the goods?

A: Of course you can.
